Flange & Spoke Load Cells and Force Transducers

Flange & Spoke Load Cells and Force Transducers for the precise measurement of tension and compression forces in an extra-flat housing. They feature excellent output symmetry between compression and tension modes and are suitable for numerous applications in mechanical and plant engineering. Nominal loads of up to 5MN or 500t are available as standard. Furthermore, we are happy to manufacture custom sensors for you.

Centered Force: Ring & Flange Load Cells and Force Transducers

Precision in a flat design. Our flange & spoke transducers (often referred to as wheel or pancake load cells) are the first choice when it comes to measuring high forces with minimal installation height and maximum stability.

• Extremely flat construction: The low profile allows for easy integration into existing machine structures where vertical space is limited.

• High stiffness & dynamics: Due to the robust wheel geometry, these cells are insensitive to eccentric loads and transverse forces – ideal for fast test cycles and fatigue testing.

• Central through-hole: Perfectly suited for passing bolts or shafts through – a specialized solution for monitoring pretension forces or mounting in presses.

• Industrial durability: Fully welded and made of stainless steel, they offer maximum reliability even under the harshest operating conditions.

Flat in design, unbeatable in stability. Optimize your force and load measurement with flange & spoke load cells and force transducers from octogon!
